Newpixel Plus

3D LED VIDEO WALLS

3D LED VIDEO WALLS

Newpixel Plus is the pinnacle of reliability when it comes to display manufacture and technology. With cutting-edge technology, their LED Walls redefine excellence and usher in a new era of visual experiences. Newpixel Plus LED Screen Panels combine state-of-the-art design with meticulous engineering to create an unmatched visual feast. These displays, with their brilliant colours and smooth transitions, redefined immersive content delivery. We are the top leader in LED walls technology; elevate your environment with their technological marvels, where trust meets innovation. Choose Newpixel Plus led screen panels for a display experience that embraces the future and goes beyond expectations.

Product Specification
Pixel Pitch (mm)1.51.92.62.93.9
LED ConfigurationSMD1212SMD1515SMD1515SMD2020SMD2020
Pixel Density (dots/m2)409,600262,144147,256112,89665,536
Brightness (cd/m2)2000nits or more2000nits or more2000nits or more2500nits or more2500nits or more
Module Size (WxH mm)250×250250×250250×500250×500250×500
Module Resolution (dots)160×160128×12896×19284×16864×128
Panel Size (WxH mm)500×500 or more500×500 or more500×500 or more500×1000 or more500×1000 or more
Panel Resolution (dots)320×320256×256192×192/384168×168/336128×128/256
Panel Weight (Kg/pc)Die-casting Mg 8.5Kg / 13.5Kg
Curved AngleSupport 60, 30, 00, +30, +60
Power Consumption 2 W/m2450 / 500 W/m2
Refresh Rate7680Hz
Gray Scale16 bits
IP GradeIP31
